M2 M3 Bi Metal Hole Saw For Stainless Steel 14mm-210mm Diameter

Brand Name:	OEM/ODM/OBM
Model Number:	M2/M3 Bi-matel hole saw
Price:	Best Factory Price
Payment Terms:	L/C T/T
Supply Ability:	400,000 units per month

Detail Information

Product Description

Detail Information

Place of Origin:

ZHEJIANG,CHINA

Certification:

ISO/BSCI

Material:

M2/M3 Bi-metal (HSS)

Size:

14-210mm

Cutting Depth:

38mm/44mm /47mm

Teeth Type:

Variable Pitch Teeth

Hardness:

63-66HRC

Arbor Type:

3/8" Hex 1/2"-20UNF For 14 To 30mm Hole Saw;7/16" Hex 5/8"-18 UNF For 32 To 210mm Hole Saw

Application:

Stainless Steel,nail-embedded Wood, Metal, Aluminium，casting Materials, Wood, Plastic Materials, Gypsum Board,ect

Concentricity Tolerance:

Less Than 0.75mm

End-face Tolerance:

Less Than 0.1mm

Packaging Details:

Double Blister/Color Paper Box

Supply Ability:

400,000 units per month

Highlight:

M3 Bi Metal Hole Saw

M2 Bi Metal Hole Saw

Metal Hole Saw For Stainless Steel

Product Description

M2 M3 Bi Metal Hole Saw For Stainless Steel 14mm-210mm Diameter

Product Specifications

Attribute	Value
Material	M2/M3 Bi-metal (HSS)
Size	14-210mm
Cutting Depth	38mm/44mm/47mm
Teeth Type	Variable Pitch Teeth
Hardness	63-66HRC
Arbor Type	3/8" Hex 1/2"-20UNF For 14 To 30mm Hole Saw; 7/16" Hex 5/8"-18 UNF For 32 To 210mm Hole Saw
Application	Stainless Steel, nail-embedded Wood, Metal, Aluminium, casting Materials, Wood, Plastic Materials, Gypsum Board, etc
Concentricity tolerance	Less Than 0.75mm
End-face tolerance	Less Than 0.1mm

Size Chart

Item No.	Inch	mm	Item No.	Inch	mm
WT-01014	9/16	14	WT-01065	2-9/16"	65
WT-01016	5/8"	16	WT-01067	2-5/8"	67
WT-01017	11/16"	17	WT-01068	2-11/16"	68
WT-01019	3/4"	19	WT-01070	2-3/4"	70
WT-01020	25/32"	20	WT-01073	2-7/8"	73
WT-01021	13/16"	21	WT-01076	3"	76
WT-01022	7/8"	22	WT-01079	3-1/8"	79
WT-01024	15/16"	24	WT-01083	3-1/4"	83
WT-01025	1"	25	WT-01086	3-3/8"	86
WT-01027	1-1/16"	27	WT-01089	3-1/2"	89
WT-01029	1-1/8	29	WT-01092	3-5/8"	92
WT-01030	1-3/16"	30	WT-01095	3-3/4"	95
WT-01032	1-1/4	32	WT-01098	3-7/8"	98
WT-01033	1-5/16"	33	WT-01102	4"	102
WT-01035	1-3/8	35	WT-01105	4-1/8"	105
WT-01037	1-7/16"	37	WT-01108	4-1/4"	108
WT-01038	1-1/2"	38	WT-01111	4-3/8"	111
WT-01040	1-9/16"	40	WT-01114	4-1/2"	114
WT-01041	1-5/8*	41	WT-01121	4-3/4"	121
WT-01043	1-11/16"	43	WT-01127	5"	127
WT-01044	1-3/4	44	WT-01133	5-1/4"	133
WT-01046	1-13/16"	46	WT-01140	5-1/2"	140
WT-01048	1-7/8	48	WT-01146	5-3/4	146
WT-01051	2"	51	WT-01152	6"	152
WT-01052	2-1/16"	52	WT-01160	6-19/64"	160
WT-01054	2-1/8	54	WT-01165	6-1/2"	165
WT-01057	2-1/4	57	WT-01168	6-5/8"	168
WT-01059	2-5/16"	59	WT-01177	6-31/32"	177
WT-01060	2-3/8	60	WT-01200	7-7/8"	200
WT-01064	2-1/2	64	WT-01210	8-17/64"	210

Key Features

High speed Steel teeth electron welded to a high Carbon steel body ensuring maximum durability and long working life
4/6 variable pitch tooth design with improved chip clearance and lower feed pressure required with varying gullet depth
Less heat build up ensures the teeth stay sharp longer
Faster and more aggressive cutting performance
Using a cooling lubricant will extend the life of your hole saw by 500%
Bimetal Hole Saws with HSS teeth are rugged cutting tools designed to cut accurate holes in machinable materials up to 38mm thick
Ranging in size from 14mm to 210mm in diameter
Compatible with portable electric tools, air tools, drill press, lathes, boring mills, milling machines and other rotating spindle machines

Technical Support & Services

Expert consultation to help determine the appropriate Bi-metal hole saw size
Detailed product specifications and usage instructions
Access to online resources and technical documentation
Product warranty and repair services
Replacement parts and accessories available for purchase

Packaging & Shipping

Product Packaging: The bi-metal hole saw comes in a sturdy cardboard box with a clear plastic window on the front. The box is labeled with the product name, size, and brand logo. Inside the box, the hole saw is securely held in place with foam padding to prevent any damage during transportation. The packaging includes an instruction manual with safety guidelines and usage instructions.

Shipping: The bi-metal hole saw is shipped in an appropriately sized cardboard box to ensure safe transportation. The box is labeled with the shipping address, return address, and product information. The hole saw is wrapped in protective material to prevent any damage during shipping. Shipment can be tracked using the provided tracking number.
