ODM OBM Bi Metal Hole Saw 32mm Hole Saw For Stainless Steel

Detail Information

Place of Origin:

ZHEJIANG,CHINA

Certification:

ISO/BSCI

Arbor Type:

3/8" Hex 1/2"-20UNF For 14 To 30mm Hole Saw;7/16" Hex 5/8"-18 UNF For 32 To 210mm Hole Saw

Concentricity Tolerance:

Less Than 0.75mm

Cutting Depth:

38mm/44mm /47mm

End-face Tolerance:

Less Than 0.1mm

Teeth Type:

Variable Pitch Teeth

Hardness:

66-69HRC

Application:

Stainless Steel,nail-embedded Wood, Metal, Aluminium，casting Materials, Wood, Plastic Materials, Gypsum Board,ect

Size:

Diameters From 9/16

Packaging Details:

Double Blister/Color Paper Box

Supply Ability:

400,000 units per month

Highlight:

Product Description

ODM OBM Bi Metal Hole Saw 32mm Hole Saw For Stainless Steel

Product Specifications

Attribute	Value
Arbor Type	3/8" Hex 1/2"-20UNF For 14 To 30mm Hole Saw; 7/16" Hex 5/8"-18 UNF For 32 To 210mm Hole Saw
Concentricity Tolerance	Less Than 0.75mm
Cutting Depth	38mm/44mm/47mm
End-face Tolerance	Less Than 0.1mm
Teeth Type	Variable Pitch Teeth
Hardness	66-69HRC
Application	Stainless Steel, nail-embedded Wood, Metal, Aluminium, casting Materials, Wood, Plastic Materials, Gypsum Board, etc
Size	Diameters From 9/16

Product Description

M42 Bi Metal Hole Saw with Cobalt 8% HSS construction, offering superior hardness (66-69HRC) for professional cutting applications.

Available Sizes

Item No.	Inch	mm	Item No.	Inch	mm
WT-01014	9/16	14	WT-01065	2-9/16"	65
WT-01016	5/8"	16	WT-01067	2-5/8"	67
WT-01017	11/16"	17	WT-01068	2-11/16"	68
WT-01019	3/4"	19	WT-01070	2-3/4"	70
WT-01020	25/32"	20	WT-01073	2-7/8"	73
WT-01021	13/16"	21	WT-01076	3"	76
WT-01022	7/8"	22	WT-01079	3-1/8"	79
WT-01024	15/16"	24	WT-01083	3-1/4"	83
WT-01025	1"	25	WT-01086	3-3/8"	86
WT-01027	1-1/16"	27	WT-01089	3-1/2"	89
WT-01029	1-1/8	29	WT-01092	3-5/8"	92
WT-01030	1-3/16"	30	WT-01095	3-3/4"	95
WT-01032	1-1/4	32	WT-01098	3-7/8"	98
WT-01033	1-5/16"	33	WT-01102	4"	102
WT-01035	1-3/8	35	WT-01105	4-1/8"	105
WT-01037	1-7/16"	37	WT-01108	4-1/4"	108
WT-01038	1-1/2"	38	WT-01111	4-3/8"	111
WT-01040	1-9/16"	40	WT-01114	4-1/2"	114
WT-01041	1-5/8*	41	WT-01121	4-3/4"	121
WT-01043	1-11/16"	43	WT-01127	5"	127
WT-01044	1-3/4	44	WT-01133	5-1/4"	133
WT-01046	1-13/16"	46	WT-01140	5-1/2"	140
WT-01048	1-7/8	48	WT-01146	5-3/4	146
WT-01051	2"	51	WT-01152	6"	152
WT-01052	2-1/16"	52	WT-01160	6-19/64"	160
WT-01054	2-1/8	54	WT-01165	6-1/2"	165
WT-01057	2-1/4	57	WT-01168	6-5/8"	168
WT-01059	2-5/16"	59	WT-01177	6-31/32"	177
WT-01060	2-3/8	60	WT-01200	7-7/8"	200
WT-01064	2-1/2	64	WT-01210	8-17/64"	210

Technical Parameters

Product Attribute	Technical Parameter
Product Name	HSS hole saw, Bi-metal core drill bit
Material	M42 Bi-metal (HSS)
Hardness	66-69HRC
End-face Tolerance	Less Than 0.1mm
Arbor Type	3/8" Hex 1/2"-20UNF For 14 To 30mm Hole Saw; 7/16" Hex 5/8"-18 UNF For 32 To 210mm Hole Saw
Application	Stainless Steel, nail-embedded Wood, Metal, Aluminium, casting Materials, Wood, Plastic Materials, Gypsum Board, etc
Teeth Type	Variable Pitch Teeth
Cutting Depth	38mm/44mm/47mm
Concentricity Tolerance	Less Than 0.75mm
Size	Diameters From 9/16
